Product Summary

The TPS77733PWPRG4 is a fast-transient-response 750-mA low-dropout voltage regulator. It is designed to have a fast transient response and be stable with a 10-μF low ESR capacitors. The TPS77733PWPRG4 provides high performance at a reasonable cost. The device behaves as a low-value resistor, the dropout voltage is very low and is directly proportional to the output current. The TPS77733PWPRG4 is offered in 1.5-V, 1.8-V, 2.5-V, and 3.3-V fixed-voltage versions and in an adjustable version.

Parametrics

TPS77733PWPRG4 absolute maximum ratings: (1)Input voltage range VI: -0.3 V to 13.5 V; (2)Voltage range at EN: -0.3 V to 16.5 V; (3)Maximum RESET voltage: 16.5 V; (4)Peak output current: Internally limited; (5)Output voltage, VO (OUT, FB): 7 V; (6)Operating virtual junction temperature range, TJ: -40℃ to 125℃; (7)Storage temperature range, Tstg: -65℃ to 150℃; (8)ESD rating, HBM: 2 kV.

Features

TPS77733PWPRG4 features: (1)Open Drain Power-On Reset With 200-ms Delay; (2)750-mA Low-Dropout Voltage Regulator; (3)Available in 1.5-V, 1.8-V, 2.5-V, 3.3-V Fixed Output and Adjustable Versions; (4)Dropout Voltage to 260 mV (Typ) at 750 mA; (5)Ultra Low 85 mA Typical Quiescent Current; (6)Fast Transient Response; (7)2% Tolerance Over Specified Conditions for Fixed-Output Versions; (8)8-Pin SOIC and 20-Pin TSSOP PowerPADE(PWP) Package; (9)Thermal Shutdown Protection.
