Product Summary

The 6N137-00ME is a single channel 10 Mbd optocoupler utilizing a high efficient input LED coupled with an integrated optical photodiode IC detector.

Parametrics

Absolute maximum ratings: (1)Average forward current: 20 mA; (2)Average forward current: 15 mA; (3)Reverse input voltage: 5 V; (4)Enable input voltage: VCC + 0.5 V V; (5)Enable input current: 5 mA; (6)Surge current: 200 mA at t = 100 μs.

Features

Features: (1)Choice of CMR performance of 10 kV/μs, 5 kV/μs, and 100 V/μs; (2)High speed: 10 Mbd typical; (3)+ 5 V CMOS compatibility; (4)Guaranteed AC and DC performance over temperature: - 40 to + 100 ℃ Temp. Range; (5)Pure tin leads; (6)Meets IEC60068-2-42 (SO2) and IEC60068-2-43 (H2S) requirements; (7)Low input current capability: 5 mA; (8)Lead (Pb)-free component; (9)Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.

Diagrams

6N134
6N134

Avago Technologies

High Speed Optocouplers 10MBd 2CH 1500Vdc Hermetically sealed

Data Sheet
