Product Summary

The HMC190MS8TR is a low cost SPDT switch in an 8-lead MSOP package. The switch can control signals from DC to 3.0 GHz. It is especially suited for low and medium power applications using positive control voltages.

Parametrics

Absolute maximum ratings: (1)Control Voltage Range (A & B): -0.2 to +12 Vdc; (2)Storage Temperature: -65 to +150 ℃; (3)Operating Temperature: -40 to +85 ℃.

Features

Features: (1)Low Insertion Loss: 0.4dB; (2)Ultra Small Package: MSOP8; (3)High Input IP3: +50 dBm; (4)Positive Control: 0/+3V @ 10 uA.

Diagrams
