Product Summary

The 74LVC1G57GW.125 is a low-power configurable multiple function gate. It is fully specified for partial power-down applications using IOFF.

Parametrics

Absolute maximum ratings: (1)VCC, supply voltage: -0.5 to +6.5 V; (2)IIK, input clamping current: -50mA max when VI < 0 V; (3)VI, input voltage: 0.5 to +6.5 V; (4)IOK, output clamping current: ±50 mA max when VO > VCC or VO < 0 V; (5)IO, output current: ±50 mA max when VO = 0 V to VCC; (6)ICC, supply current:+100 mA max; (7)IGND, ground current: -100 mA min; (8)Tstg, storage temperature: -65 +150 ℃ (9)Ptot, total power dissipation: 250 mW when Tamb = -40 ℃to +125 ℃.

Features

Features: (1)Wide supply voltage range from 1.65 V to 5.5 V; (2)5 V tolerant input/output for interfacing with 5 V logic; (3)High noise immunity; (4)ESD protection: HBM JESD22-A114F exceeds 2000 V; MM JESD22-A115-A exceeds 200 V; (5)±24 mA output drive (VCC = 3.0 V); (6)CMOS low power consumption; (7)Latch-up performance exceeds 250 mA; (8)Direct interface with TTL levels; (9)Inputs accept voltages up to 5 V; (10)Multiple package options.
