Product Summary
The SN74AHCT86PWR is a quadruple 2-input exclusive-OR gate. The SN74AHCT86PWR performs the Boolean function Y = A+B or Y = AB + AB in positive logic.
Parametrics
SN74AHCT86PWR absolute maximum ratings: (1)Supply voltage range, VCC:–0.5 V to 7 V; (2)Input voltage range, VI:–0.5 V to 7 V; (3)Output voltage range, VO: –0.5 V to VCC + 0.5 V; (4)Input clamp current, IIK (VI＜0): –20 mA; (5)Output clamp current, IOK (VO＜ 0 or VO＞ VCC): ±20 mA; (6)Continuous output current, IO (VO = 0 to VCC): ±25 mA; (7)Continuous current through VCC or GND: ±50 mA; (8)Package thermal impedance, θJA: D package: 86℃/W; (9)DB package: 96℃/W; (10)DGV package: 127℃/W; (11)N package: 80℃/W; (12)NS package: 76℃/W; (13)PW package: 113℃/W; (14)RGY package: 47℃/W; (15)Storage temperature range, Tstg: –65℃ to 150℃.
Features
SN74AHCT86PWR features: (1)Inputs Are TTL-Voltage Compatible; (2)Latch-Up Performance Exceeds 250 mA Per JESD 17; (3)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114A) 200-V Machine Model (A115-A).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74AHCT86PWR |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quad 2 Input |
Data Sheet |
|
|
||||||||||||
|
SN74AHCT86PWRE4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Exclusive-OR Gate |
Data Sheet |
|
|
||||||||||||
|
SN74AHCT86PWRG4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Exclusive-OR Gate |
Data Sheet |
|
|
||||||||||||
