SN74ABT16244ADGGR

SN74ABT16244ADGGR, 16-bit buffer/driver, TSSOP48, –0.5V to 7V, 128mA, -50mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.32~0.32 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.32~0.32

PartNumber:: SN74ABT16244ADGGR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-07

From Other Seller

Part Number:SN74ABT16244ADGGR
US $0.32 - 0.32
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN74ABT16244ADGGR is a 16-bit buffer/driver with 3-state outputs. The SN74ABT16244ADGGR is designed specifically to improve both the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. The SN74ABT16244ADGGR can be used as four 4-bit buffers, two 8-bit buffers, or one 16-bit buffer. It provides true outputs and symmetrical OE (active-low output-enable) inputs.

Parametrics

SN74ABT16244ADGGR absolute maximum ratings: (1)VCC Supply voltage range: –0.5V to 7V; (2)VI Input voltage range: –0.5V to 7V; (3)VO Voltage range applied to any output in the high or power-off state: –0.5V to 5.5V; (4)IO Current into any output in the low state: 128mA; (5)IIK Input clamp current VI＜0: –18 mA; (6)IOK Output clamp current VO＜0:–50 mA; (7)θJA Package thermal impedance: 89℃/W; (8)Tstg Storage temperature range: –65℃ to 150℃.

Features

SN74ABT16244ADGGR features: (1) Members of the Texas Instruments Widebus Family; (2) State-of-the-Art EPIC-IIB. BiCMOS Design Significantly Reduces Power Dissipation; (3) Latch-Up Performance Exceeds 500 mA Per JESD 70; (4)Typical VOLP (Output Ground Bounce)＜1 V at VCC = 5 V, TA = 25℃; (5)Distributed VCC and GND Pin Configuration Minimizes High-Speed Switching Noise; (6)Flow-Through Architecture Optimizes PCB Layout; (7)High-Drive Outputs (–32-mA IOH, 64-mA IOL); (8)Package Options Include Plastic 300-mil Shrink Small-Outline (DL), Thin Shrink Small-Outline (DGG), and Thin Very Small-Outline (DGV) Packages and 380-mil Fine-Pitch Ceramic Flat (WD) Package Using 25-mil Center-to-Center Spacings.
