Product Summary
The SN54LS367AJ is a HEX bus driver with 3-state outputs. The Hex buffer and line driver are designed specifically to improve both the performance and density of three-state memory address drivers, clock drivers, and bus oriented receivers and transmitters. The designer has choice of selected combinations of inverting and noninverting outputs, symmetrical G (active-low control) inputs. The SN54LS367AJ features high fan-out, improved fan-in, and can be used to drive terminated lines down to 1 33 ohms. The SN54LS367AJ is characterized for operation over the full military temperature range of -55℃ to 125℃.
Parametrics
SN54LS367AJ absolute maximum ratings: (1)Supply voltage, VCC: 7V; (2)Input voltage: 7V; (3)Voltage applied to a disabled 3-stste output: 5.5V; (4)Operating free-air temperature: -55℃ to +125℃; (5)Storage temperature range: -65℃ to 150℃.
Features
SN54LS367AJ features: (1)3-statee outputs drive bus lines or buffer memory address registors; (2)Choice of true or inverting outputs; (3)Package options include plastic "small outline" packages, ceramic chip carriers and flat packages, and plastic and ceramic DIPs; (4)Dependable texas instruments quality and reliability.
Diagrams
 |
