Product Summary

The MP3302 is a step-up converter designed for driving arrays of WLEDS from a single cell Lithium Ion battery. The MP3302 uses current mode, fixed frequency architecture to regulate the LED current, which is measured through an external current sense resistor. Its low 200mV feedback voltage reduces power loss and improves efficiency. The MP3302 is turned off if an over-voltage condition is present due to an open circuit condition.

Parametrics

MP3302 absolute maximum ratings: (1)SW Pin:–0.5V to +44V ; (2)All Other Pins:–0.3V to +6.5V ; (3)Continuous Power Dissipation(TA = +25℃): TSOT23-5:0.57W, QFN8 (2mm x 3mm):1.56W; (4)Storage Temperature:–55℃ to +150℃; (5)IN Supply Voltage:2.5V to 6V ; (6)SW Pin:VIN to 36V ; (7)Operating Junction Temp:–40℃ to +125℃.

Features

MP3302 features: (1)Internal Power MOSFET ; (2)Drives up to 10 Series White LEDs ; (3)Up to 87% Efficiency ; (4)Single Wire Dimming Control ; (5)1.3MHz Fixed Switching Frequency ; (6)Open Load Shutdown ; (7)Low 200mV Feedback Voltage ; (8)UVLO, Thermal Shutdown ; (9)Internal 1.3A Current Limit ; (10)Available in TSOT23-5 and 2mm x 3mm QFN8 Packages.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MP3302
MP3302

Other


Data Sheet

Negotiable
MP3302DD-LF-P
MP3302DD-LF-P

Monolithic Power Systems (MPS)

LED Lighting Drivers 1.3A, 1.3MHz WLED Driver

Data Sheet

0-1: $1.34
1-25: $1.25
25-100: $1.15
100-500: $1.06
MP3302DD-LF-Z
MP3302DD-LF-Z

Monolithic Power Systems (MPS)

LED Lighting Drivers 1.3A, 1.3MHz WLED Driver

Data Sheet

0-3680: $0.79
3680-5000: $0.78
MP3302DJ-LF-P
MP3302DJ-LF-P

Monolithic Power Systems (MPS)

LED Lighting Drivers 1.3A, 1.3MHz WLED Driver

Data Sheet

0-1: $1.34
1-25: $1.25
25-100: $1.15
100-500: $1.06
MP3302DJ-LF-Z
MP3302DJ-LF-Z

Monolithic Power Systems (MPS)

LED Lighting Drivers 1.3A, 1.3MHz WLED Driver

Data Sheet

0-2210: $0.79
2210-3000: $0.79
3000-5000: $0.78
