Product Summary

The LF347DR is a low-cost, high-speed, JFET-input operational amplifier. It requires low supply current yet maintain a large gain-bandwidth product and a fast slew rate. In addition, the matched high-voltage JFET inputs of LF347DR provide very low input bias and offset current. The LF347DR can be used in applications such as high-speed integrators, digital-to-analog converters, sample-and-hold circuits, and many other circuits. It is characterized for operation from 0℃ to 70℃.

Parametrics

LF347DR absolute maximum ratings: (1)Supply voltage, VCC +: 18 V; (2)Supply voltage, VCC –: –18 V; (3)Differential input voltage, VID: ±30 V; (4)Input voltage, VI: ±15 V; (5)Duration of output short circuit: unlimited; (6)Operating temperature range: 0℃ to 70℃; (7)Storage temperature range: –65℃ to 150℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

LF347DR features: (1)Low Input Bias Current: 50 pA Typ; (2)Low Input Noise Current: 0.01 pA/√Hz Typ; (3)Low Total Harmonic Distortion; (4)Low Supply Current: 8 mA Typ; (5)Gain Bandwidth: 3 MHz Typ; (6)High Slew Rate: 13 V/μs Typ; (7)Pin Compatible With the LM348.

Diagrams

LF347DR pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LF347DR
LF347DR
Texas Instruments
Operational Amplifiers - Op Amps Quad WB JFET Op Amp
Data Sheet
0-1: $0.35
1-25: $0.27
25-100: $0.24
100-250: $0.21
LF347DRE4
LF347DRE4
Texas Instruments
Operational Amplifiers - Op Amps Quad JFET-input
Data Sheet
0-1: $0.37
1-25: $0.29
25-100: $0.25
100-250: $0.22
LF347DRG4
LF347DRG4
Texas Instruments
Operational Amplifiers - Op Amps Quad Gen-Purp JFET- input Op Amp
Data Sheet
0-1: $0.37
1-25: $0.29
25-100: $0.25
100-250: $0.22
