74VHC273MTCX

Octal D-Type Flip-Flop, 74VHC273MTCX, SOP20, –0.5V to +7.0V, ±20mA, ±75mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.10

PartNumber:: 74VHC273MTCX

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-16

From Other Seller

Part Number:74VHC273MTCX
US $0.10 - 0.10
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 74VHC273MTCX is an advanced high speed CMOS Octal D-type flip-flop fabricated with silicon gate CMOS technology. The 74VHC273MTCX achieves the high speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation. The 74VHC273MTCX can be used to interface 5V to 3V systems and two supply systems such as battery backup. This circuit prevents device destruction due to mismatched supply and input voltages.

Parametrics

74VHC273MTCX absolute maximum ratings: (1)Supply Voltage: –0.5V to +7.0V; (2)DC Input Voltage: –0.5V to +7.0V; (3)DC Output Voltage: –0.5V to VCC + 0.5V; (4)Input Diode Current: –20mA; (5)Output Diode Current: ±20mA; (6)DC Output Current: ±25mA; (7)DC VCC/GND Current: ±75mA; (8)Storage Temperature: –65℃ to +150℃; (9)Lead Temperature (Soldering, 10 seconds): 260℃.

Features

74VHC273MTCX features: (1)High Speed: fMAX = 165MHz (typ) at VCC = 5V; (2)Low power dissipation: ICC = 4μA (max) at TA =25℃; (3)High noise immunity: VNIH = VNIL = 28% VCC (min); (4) Power down protection is provided on all inputs; (5) Low noise: VOLP = 0.9V (max); (6) Pin and function compatible with 74HC273; (7) Leadless DQFN Package.
