Product Summary
The DM74ALS541SJ octal buffer and line driver is designed to have the performance of the DM74ALS240A series and, at the same time, offer a pinout with inputs and outputs on opposite sides of the package.
Parametrics
Absolute maximum ratings: (1)Supply Voltage: 7V; (2)Input Voltage: Control Inputs 7V; (3)Voltage Applied to a Disabled 3-STATE Output: 5.5V; (4)Operating Free-Air Temperature Range: 0℃ to +70℃; (5)Storage Temperature Range: -65℃ to +150℃; (6)Typical qJA: N Package: 58.5℃/W, M Package: 77.5℃/W.
Features
Features: (1)Advanced oxide-isolated ion-implanted Schottky TTL process; (2)Switching performance is guaranteed over full temperature and VCC supply range; (3)Data flow-thru pinout (all inputs on opposite side from outputs); (4)P-N-P Inputs reduce DC loading.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
DM74ALS541SJ |
IC BUFF/DVR TRI-ST 8BIT 20SOP |
Data Sheet |
Negotiable |
|
||||||
DM74ALS541SJ_Q |
Fairchild Semiconductor |
Buffers & Line Drivers Oct Buf and Line Drv |
Data Sheet |
Negotiable |
|
|||||
DM74ALS541SJX |
Fairchild Semiconductor |
Buffers & Line Drivers Oct Buf and Line Drv |
Data Sheet |
Negotiable |
|
