Product Summary
The ULN2004AFWG is a high-voltage, high-current darlington driver, which is comprised of seven NPN darlington pairs. All units feature integral clamp diodes for switching inductive loads. The applicantions of the ULN2004AFWG include relay, hammer, lamp and display(LED) drivers.
Parametrics
ULN2004AFWG absolute maximum ratings: (1)Output sustaining voltage: -0.5~50 V ; (2)Output current: 500 mA/ch ; (3)Input voltage: -0.5~30 V ; (4)Clamp diode reverse voltage: 50 V ; (5)Clamp diode forward current: 500 mA ; (6)Power dissipation: APG: 1.47 W, AFWG: 0.54/0.625 (Note) W; (7)Operating temperature: -40~85 ℃ ; (8)Storage temperature: -55~150 ℃.
Features
ULN2004AFWG features: (1)Output current (single output): 500 mA max; (2)High sustaining voltage output: 50 V min; (3)Output clamp diodes; (4)Inputs compatible with various types of logic; (5)Package Type-APG: DIP-16pin; (6)Package Type-AFWG: SOL-16pin.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ULN2004AFWG |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2004AFWG(5,EL,M |
Toshiba |
Transistors Darlington 7CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2004AFWG(O,EL,M |
Toshiba |
Transistors Darlington 7-ch 500mA 50V 10.5 kOhm 6 to 15V |
Data Sheet |
|
|
||||||||||||
|
ULN2004AFWG(O,M) |
Toshiba |
Transistors Darlington 7-ch 500mA 50V 10.5 kOhm 6 to 15V |
Data Sheet |
|
|
||||||||||||
 |
ULN2004AFWG(O,NEHZ |
Toshiba |
Transistors Darlington 7-Ch 500mA 50V NPN Darlington Trans |
Data Sheet |
|
|
||||||||||||
|
ULN2004AFWG(5,M) |
Toshiba |
Transistors Darlington 7CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
