Product Summary
The TLE6210GC1 is an ABS System IC. It consists of a 5 V voltage regulator with 800 mA current capability, different relay driver outputs and supervision logic. The supervision logic watches the input voltage and the regulator output voltage both for over-voltage and under-voltage. In addition two window watchdogs supervise the correct operation of 2 independent watchdog signals, e.g. from two Microcontrollers. The TLE6210GC1 is designed especially for the severe conditions of ABS/ASR applications in an automotive environment.
Parametrics
TLE6210GC1 absolute maximum ratings: (1)Supply Voltage variation:|10|V/μs; (2)Output voltage at VR, MR: 60 V ; (3)Output voltage at SILA:42 V ; (4)Output voltage at NSILA:42 V ; (5)Output voltage at RES1, RES2:-0.5V to 7V ; (6)Output voltage at EN:-0.5V to 7V ; (7)Input Voltage at WD1, WD2, MRA, SIA:-0.5V to 7V ; (8)Voltage UCP:-0.5V to 20V ; (9)Storage Temperature:-55℃ to 150℃; (10)Junction Temperature:continuous:-40℃ to 150℃, short term(< 50 h over lifetime):175℃.
Features
TLE6210GC1 features: (1)5 V, 800 mA linear regulator; (2)Undervoltage/overvoltage reset; (3)Undervoltage and overvoltage logout; (4)Digital watchdog supervision for 2 Microcontrollers; (5)(motor) relay driver; (6)(valve) relay driver; (7)Inverted or non inverted lamp relay driver; (8)Enable output; (9)Overtemperature and overcurrent protection.
Diagrams
 |
