Product Summary

The SN74LV02ADR is a quadruple 2-input positive-NOR gate designed for 2-V to 5.5-V VCC operation. It is fully specified for partial-power-down applications using Ioff.

Parametrics

Absolute maximum ratings: (1)Supply voltage range, VCC: -0.5 V to 7 V; (2)Input voltage range, VI:0.5 V to 7 V; (3)Voltage range applied to any output in the high-impedance or power-off state, VO: -0.5 V to 7 V; (5)Output voltage range, VO: -0.5 V to VCC + 0.5 V; (5)Input clamp current, IIK (VI < 0): -20 mA; (6)Output clamp current, IOK (VO < 0): -50 mA.

Features

Features: (1)2-V to 5.5-V VCC Operation; (2)Max tpd of 6.5 ns at 5 V; (3)Support Mixed-Mode Voltage Operation on All Ports; (4)Ioff Supports Partial-Power-Down Mode Operation; (5)Latch-Up Performance Exceeds 250 mA Per JESD 17.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74LV02ADR
SN74LV02ADR
Texas Instruments
Gates (AND / NAND / OR / NOR) Quadruple 2-Inputs Positive-NOR Gate
Data Sheet
0-1: $0.37
1-25: $0.29
25-100: $0.25
100-250: $0.22
SN74LV02ADRE4
SN74LV02ADRE4
Texas Instruments
Gates (AND / NAND / OR / NOR) Quadruple 2-Inputs Positive-NOR Gate
Data Sheet
0-1: $0.32
1-25: $0.25
25-100: $0.22
100-250: $0.19
SN74LV02ADRG4
SN74LV02ADRG4
Texas Instruments
Gates (AND / NAND / OR / NOR) Quad 2 Input Pos Nor Gates
Data Sheet
0-1: $0.32
1-25: $0.25
25-100: $0.22
100-250: $0.19
