Product Summary
The SN74LVC244APWR is an octal buffer/driver with 3-state outputs. The SN74LVC244APWR is operational at 1.5-V to 3.6-V VCC, but is designed specifically for 1.65-V to 3.6-V VCC operation. The SN74LVC244APWR is organized as two 4-bit line drivers with separate output-enable (OE) inputs. When OE is low, the device passes data from the A inputs to the Y outputs. When OE is high, the outputs are in the high-impedance state. Inputs can be driven from either 3.3-V or 5-V devices. This feature allows the use of this device as a translator in a mixed 3.3-V/5-V system environment.
Parametrics
SN74LVC244APWR absolute maximum ratings: (1)Supply voltage range: -0.5V to 6.5V; (2)Input voltage range: -0.5V to 6.5V; (3)Voltage range applied to any output in the high-impedance or power-off state: -0.5V to 6.5V; (4)Voltage range applied to any output in the high or low state:-0.5V to VCC+0.5V; (5)Input clamp current VI＜0: -50mA; (6)Output clamp current VO＜0: -50mA; (7)Continuous output current: ±50mA; (8)Continuous current through VCC or GND: ±100mA; (9)θJA Package thermal impedance: 83℃/W; (10)Storage temperature range: -65℃ to 150℃; (11)Power dissipation TA= -40℃ to 125℃: 500mW.
Features
SN74LVC244APWR features: (1)Operates From 1.65V to 3.6V; (2)Inputs Accept Voltages to 5.5V; (3)Specified From –40℃ to 85℃ and –40℃ to 125℃; (4)Max tpd of 5.9ns at 3.3V; (5)Typical VOLP (Output Ground Bounce)＜0.8V at VCC = 3.3V, TA=25℃; (6)Typical VOHV (Output VOH Undershoot)＞2V at VCC = 3.3V, TA=25℃; (7)Supports Mixed-Mode Signal Operation on All Ports (5-V Input/Output Voltage with 3.3-V VCC); (8) Ioff Supports Partial-Power-Down Mode Operation; (9) Latch-Up Performance Exceeds 250mA Per JESD 17; (10) ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), 1000-V Charged-Device Model (C101).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74LVC244APWR |
Texas Instruments |
Buffers & Line Drivers Tri-State Octal |
Data Sheet |
|
|
||||||||||||
|
SN74LVC244APWRE4 |
Texas Instruments |
Buffers & Line Drivers Octal Buffer/Driver W/3-State Output |
Data Sheet |
|
|
||||||||||||
|
SN74LVC244APWRG3 |
Texas Instruments |
Buffers & Line Drivers Octal Buffer/Driver |
Data Sheet |
|
|
||||||||||||
|
SN74LVC244APWRG4 |
Texas Instruments |
Buffers & Line Drivers Octal Buffer/Driver W/3-State Output |
Data Sheet |
|
|
||||||||||||
