Product Summary
The SN74F280BDR is a 9-bit parity generator/checker. The SN74F280BDR features odd and even outputs to facilitate operation of either odd or even parity application. The word-length capability is easily expanded by cascading. The SN74F280BDR is characterized for operation over the full military temperature range of 0℃ to 70℃.
Parametrics
SN74F280BDR absolute maximum ratings: (1)Supply voltage range, VCC:–0.5V to 7V; (2)Input voltage range:–1.2V to 7V; (3)Input current range:–30mA to 5mA; (4)Voltage range applied to any output in the high state:–0.5V to VCC; (5)Current into any output in the low state: 40mA; (6)Operating free-air temperature range: 0℃ to 70℃; (7)Storage temperature range:–65℃ to 150℃.
Features
SN74F280BDR features: (1)Generates Either Odd or Even Parity for Nine Data Lines; (2) Cascadable for N-Bits Parity; (3)Package Options Include Plastic Small-Outline Packages, Ceramic Chip Carriers, and Standard Plastic and Ceramic 300-mil DIPs.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74F280BDR |
Texas Instruments |
Parity Functions 9-bit odd/evn parity Generator/Checker |
Data Sheet |
|
|
||||||||||||
|
SN74F280BDRE4 |
Texas Instruments |
Parity Functions 9-bit odd/evn parity Generator/Checker |
Data Sheet |
|
|
||||||||||||
|
SN74F280BDRG4 |
Texas Instruments |
Parity Functions 9B Odd Even Parity Generators Checkers |
Data Sheet |
|
|
||||||||||||
