Product Summary

Parametrics

Manufacturer: Texas Instruments
Features: -
Logic Type: NAND Gate
Voltage - Supply: 4.5 V ~ 5.5 V
Logic Level - High: 2V
Logic Level - Low: 0.8V
Number of Circuits: 2
Number of Inputs: 4
Current - Quiescent (Max): -
Operating Temperature: 0°C ~ 70°C
Mounting Type: Through Hole
Supplier Device Package: 14-PDIP
Package / Case: 14-DIP (0.300", 7.62mm)
Packaging: Tube
Series: 74AS
Current - Output High, Low: 2mA, 20mA
Max Propagation Delay @ V, Max CL: 5ns @ 4.5V ~ 5.5V, 50pF

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74AS20N
SN74AS20N
Texas Instruments
Gates (AND / NAND / OR / NOR) Dual 4-Input Positive-NAND gates
Data Sheet
0-1: $1.38
1-25: $1.20
25-100: $1.09
100-250: $0.96
SN74AS20NE4
SN74AS20NE4
Texas Instruments
Gates (AND / NAND / OR / NOR) Dual 4-Input Positive-NAND gates
Data Sheet
0-1: $1.34
1-25: $1.08
25-100: $0.98
100-250: $0.89
SN74AS20NSR
SN74AS20NSR
Texas Instruments
Gates (AND / NAND / OR / NOR) Dual 4-Input Positive-NAND gates
Data Sheet
0-1430: $0.67
1430-2000: $0.64
2000-5000: $0.61
5000-10000: $0.59
SN74AS20NSRE4
SN74AS20NSRE4
Texas Instruments
Gates (AND / NAND / OR / NOR) Dual 4-Input Positive-NAND gates
Data Sheet
0-1430: $0.67
1430-2000: $0.64
2000-5000: $0.61
5000-10000: $0.59
SN74AS20NSRG4
SN74AS20NSRG4
Texas Instruments
Gates (AND / NAND / OR / NOR) Dual 4Input Pos NAND Gates
Data Sheet
0-1430: $0.67
1430-2000: $0.64
2000-5000: $0.61
5000-10000: $0.59
