Product Summary
The SN74AHC32DR is a quadruple 2-input positive-OR gate. The SN74AHC32DR performs the Boolean function Y=A×B or Y=A+B in positive logic.
Parametrics
SN74AHC32DR absolute maximum ratings: (1)Supply voltage range, VCC:–0.5 V to 7 V; (2)Input voltage range, VI:–0.5 V to 7 V; (3)Output voltage range, VO: –0.5 V to VCC + 0.5 V; (4)Input clamp current, IIK (VI＜0): -20 mA; (5)Output clamp current, IOK (VO＜0 or VO＞VCC): ±20 mA; (6)Continuous output current, IO (VO = 0 to VCC): ±25 mA; (7)Continuous current through VCC or GND： ±50 mA; (8)Package thermal impedance, θJA: D package：86℃/W; (9)Storage temperature range, Tstg：–65℃ to 150℃.
Features
SN74AHC32DR features: (1)Operating Range 2-V to 5.5-V VCC; (2)Latch-Up Performance Exceeds 250 mA Per JESD 17; (3)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), 1000-V Charged-Device Model (C101).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74AHC32DR |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quad 2-Input Pos |
Data Sheet |
|
|
||||||||||||
|
SN74AHC32DRG4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quad 2 Input Pos OR Gates |
Data Sheet |
|
|
||||||||||||
|
SN74AHC32DRE4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-OR Gates |
Data Sheet |
|
|
||||||||||||
