Product Summary
The OPA2347UA/2K5 is a microPower, low-cost operational amplifier available in micropackages. The device is available in the SOT23-8 and WCSP-8 packages. The applications of the OPA2347UA/2K5 include portable equipment, battery-powered equipment, 2-wire transmitters, smoke detectors and co detectors. The small size and low power consumption of the OPA2347UA/2K5 make it ideal for portable and battery-powered applications. The input range of the OPA2347UA/2K5 extends 200mV beyond the rails, and the output range is within 5mV of the rails.
Parametrics
OPA2347UA/2K5 absolute maximum ratings: (1)Supply Voltage, V+ to V–: 7.5V; (2)Signal Input Terminals, Voltage: (V–) – 0.5V to (V+) + 0.5V; (3)Current: 10mA; (4)Output Short-Circuit: Continuous; (5)Operating Temperature: –65 to +150℃; (6)Storage Temperature: –65 to +150℃; (7)Junction Temperature: 150℃.
Features
OPA2347UA/2K5 features: (1) low IQ: 20μA; (2) microsize packages: WCSP-8, SC70-5, SOT23-5, SOT23-8, and TSSOP-14; (3) High speed/power ratio with bandwidth: 350kHz; (4) rail-to-rail input and output; (5)single supply: 2.3V to 5.5V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OPA2347UA/2K5 |
Texas Instruments |
Operational Amplifiers - Op Amps Micropower Rail-to-Rail |
Data Sheet |
|
|
||||||||||||
|
OPA2347UA/2K5G4 |
Texas Instruments |
Operational Amplifiers - Op Amps Micropower Rail-to-Rail |
Data Sheet |
|
|
||||||||||||
