Product Summary
The MC1315P is a DC logic enhancement control unit. The MC1315P conforms to pecihcations for decoding quadraphonic records produced by the ugest record companies tn the world. The MC1315P provides the basic logic function to enhance the front to tack separation in the CBS SQ four channel decoding system. This levice is designed to interface with the MC1312 decoder and MC1314. The MC1315P provides dc logic enhancement control signals which intends the perfofmance of the basic SQ system to the levels desired of top of the Ihil1 systems.
Parametrics
MC1315P absolute maximum ratings: (1)Supply Voltaga: ±25V; (2)Input Signal Voltage: ±4.0Vpk; (3)Bias Terminal Current: ±2.0mA; (4)Output Current: ±2.0mA; (5)Power Dissipation @ Ta = 25=℃: 750mW; (6)Derats above +25℃: 6.7mW/℃; (7)Operating Temperature Range: 0 to +70℃; (8)Storage Temperature Range: -65 to +150℃.
Features
MC1315P features: (1)Supply Current @ Vin = 0: 7.0 to 13mA; @VIN = 1.4Vrms: 15mA; (2)Input Resistance: 20kΩ; (3)Output Revstance: 1.5kΩ; (4)Filter Resistance: 4.0kΩ; (5)Front Back Logic Discharge Resistance: 5.0kΩ; (6)Voltage (10 k to Qrouad): 1.4Vdc; (7)logic Control Input Current: 0.5mA.
