LV5803M-TE-L-E

1ch step-down switching regulator, MFP8, 4.5V to 18V, 2A, LV5803M-TE-L-E

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.71~0.72 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.71~0.72

PartNumber:: LV5803M-TE-L-E

Brand:: Sanyo Semicon Device - SANYO | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-04

From Other Seller

Part Number:LV5803M-TE-L-E
US $0.71 - 0.72
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LV5803M-TE-L-E is a 1ch step-down switching regulator. 0.2Ω FET is incorporated on the upper side to achieve high-efficiency operation for large output current. Low-heat resistance and compact-package MFP8 employed. The LV5803M-TE-L-E, with superior load current response and easy phase compensation ON/OFF pin, allowing the standby mode with the current drain of 80μA or less Pulse-by-pulse over-current protection and overheat protection available for protection of the LV5803M-TE-L-E Soft start pin to be provided with a capacitance for soft start.

Parametrics

LV5803M-TE-L-E absolute maximum ratings: (1)Maximum input VIN voltage VIN max: 20 V; (2)BOOT pin maximum voltage VBT max: 25 V; (3)SW pin maximum voltage VSW max: VIN max V; (4)BOOT pin-SW pin maximum voltage VBS-SW max: 7 V; (5)EN pin maximum voltage VEN max: 20 V; (6)FB, COMP, SS pin maximum voltage Vfs max: 7 V; (7)Allowable power dissipation Pd max: 1.15 W; (8)Junction temperature Tj max: 150 ℃; (9)Operating temperature Topr: -20 to 80 ℃; (10)Storage temperature Tstg: -40 to 150 ℃.

Features

LV5803M-TE-L-E features: (1)2A 1ch step-down switching regulator; (2)Wide input dynamic range (4.5 to 18V); (3)High efficiency (90% IOUT = 1A, VIN = 12V, VO = 5V); (4)Standby mode; (5)Over-current protection; (6)Thermal shutdown; (7)Reference voltage: 0.8V; (8)Fixed frequency: 330kHz; (9)Soft start; (10)Compact package: MFP8 (225mil).
