EUP7967

300mA Low-Noise Low-Dropout, Linear Regulator, SOT, Low 84uA No-Load Supply Current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.00~5.00

PartNumber:: EUP7967

Brand:: Eutech Microelectronics Inc - EUTECH | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-29

From Other Seller

Part Number:EUP7967
US $0.00 - 5.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The EUP7967 is a low-noise, low-dropout, linear regulator operates from a 2.5V to 5.5V input and is guaranteed to deliver 300mA. The EUP7967 is stable with small 2.2uF ceramic capacitor. Its performance suits battery powered applications because of its shutdown mode, low quiescent current, and very low dropout voltage. The applications of the EUP7967 are Wireless Handsets, DSP Core Power, Battery Powered Electronics, Portable Information Appliance.

Parametrics

EUP7967 absolute maximum ratings: (1)VIN,VEN:-0.3 to 6V; (2)VOUT:-0.3 to (VIN+0.3) ≤ 6V; (3)Junction Temperature:150℃; (4)Storage Temperature:-65℃ to +150℃; (5)Lead Temp:235℃; (6)Pad Temp:235℃; (7)Maximum Power Dissipation SOT23-5:364mW; (8)Thermal Resistance θJA(SOT23-5):220℃/W; (9)ESD Rating: Human Body Model:2kV.

Features

EUP7967 features: (1)300mA Guaranteed Output Current; (2)65dB PSRR at 1kHz; (3)Low Noise Output; (4)150mV Dropout at 300mA Load; (5)Low 84μA No-Load Supply Current; (6)≤ 1μA Shutdown Current; (7)Stable With 2.2μF Ceramic Output Capacitors; (8)Thermal Shutdown and Short-Circuit Protection; (9)SOT23-5 Package; (10)RoHS Compliant and 100% Lead (Pb)-Free.
