Product Summary
The BTA204W-600E is a three quadrant triac. Passivated guaranteed commutation triacs in a plastic envelope suitable for surface mounting, intended for use in motor control circuits or with other highly inductive loads. The BTA204W-600E balances the requirements of commutation performance and gate sensitivity. The "sensitive gate" E series and "logic level" D series are intended for interfacing with low power drivers, including micro controllers.
Parametrics
BTA204W-600E absolute maximum ratings: (1)Repetitive peak off-state voltages: ±600V; (2)RMS on-state current (full sine wave, ISP≤108℃): 1A; (3)Non-repetitive peak on-state current (Tj = 25℃ prior to surge, t=20ms): 10A, t=16.7ms: 11A; (4)I2t for fusing t=10 ms: -0.5 A2s; (5)Repetitive rate of rise of on-state current after triggering: ITM = 1.5A, 100A/ms, dIG/dt = 0.2 A/ms; (6)Peak gate current: 2A; (7)Peak gate voltage: 5V; (8)Peak gate power: 5W; (9)Average gate power (over any 20 ms period): 0.5W; (10)Storage temperature: -40℃ to 150℃; (11)Operating junction temperature: 125℃.
Features
BTA204W-600E features: (1) Gate trigger current: 10mA; (2) Latching current (VD=12V, IGT=0.1A): 12mA; (3) Holding current (VD=12V, IGT=0.1A): 12mA; (4) On-state voltage (IT=2A): 1.5V; (5) Gate trigger voltage: 0.25V; (6) Off-state leakage current: 0.5mA.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BTA204W-600E |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BTA204W-600E /T3 |
NXP Semiconductors |
Triacs TAPE13 3Q TRIAC |
Data Sheet |
Negotiable |
|
||||||||||||
|
BTA204W-600E,135 |
NXP Semiconductors |
Triacs TAPE13 3Q TRIAC |
Data Sheet |
|
|
||||||||||||
