Product Summary

The AFCT-5943ALZ is a Single Mode SFF Transceiver. The AFCT-5943ALZ is designed to provide SONET/SDH compliant links at 2488 Mb/s for short reach links. The applications of the AFCT-5943ALZ include SONET/SDH equipment interconnect, Multirate Client Interface on Metro Gateways and Edge Switches.

Parametrics

AFCT-5943ALZ absolute maximum ratings: (1)Storage Temperature: -40℃ to +85℃; (2)Supply Voltage: -0.5V to 3.6V; (3)Data Input Voltage: -0.5 to VCC V; (4)Data Output Current: 50 mA; (5)Relative Humidity: 0 to 85 %; (6)Receiver Optical Input: 6 dBm.

Features

AFCT-5943ALZ features: (1)Multirate operation from 125 Mb/s to 2.7 Gb/s; (2)AFCT-5943LZ/ALZ: Links of 2 km with 9/125μm single mode fiber (SMF); (3)Multisourced 2×5 package style with LC receptacle; (4)Single +3.3 V power supply; (5)Temperature　range: -40℃ to +85℃; (6)Wave solder and aqueous wash process compatible; (7)　Manufactured in an ISO9002 certified facility; (8)RoHS compliant; (9)　Fully Class 1 CDRH/IEC 825 compliant; (10)Compliant with ITU-T G.957, STM-16, I-16 and S-16.1; (11)　Optical Interfaces; (12)AFCT-5943LZ/ALZ: with EMI shield; (13)　Receiver output squelch function enabled.
