Product Summary

The STPR1020CT is a dual center tap rectifier suited for Switched Mode Power Supplies and high frequency DC to DC converters. Packaged in DPAK, D2PAK, I2PAK, TO-220AB, TO-220FPAB or ISOWATT220AB, the STPR1020CT is intended for use in low voltage, high frequency inverters, free wheeling and polarity protection applications.

Parametrics

STPR1020CT absolute maximum ratings: (1)VRRM Repetitive peak reverse voltage: 200 V; (2)IF(RMS)RMS forward current: 10 A; (3)IF(AV)Average forward current: 5 A; (4)ISOWATT220AB Tc=115℃ Per device: 10A; (5)TO-220FPAB Tc=110℃ Per device: 10A; (6)IFSM Surge non repetitive forward current tp=10ms sinusoidal: 50 A; (7)Tstg Storage temperature range: - 65 to + 150 ℃.

Features

STPR1020CT features: (1)suited for SMPS; (2)low losses; (3)low forward and reverse recovery time; (4)high surge current capability; (5)insulated packages: ISOWATT220AB / TO-220FPAB insulatiovoltage = 2000V DC capacitance = 12 pF.

Diagrams

STPR1020CT pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
STPR1020CT
STPR1020CT

STMicroelectronics

Rectifiers 2X5 Amp 200 Volt

Data Sheet

Negotiable
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
STPR1020CB-TR
STPR1020CB-TR

STMicroelectronics

Rectifiers 2X5 Amp 200 Volt

Data Sheet

Negotiable
STPR1020CFP
STPR1020CFP

STMicroelectronics

Rectifiers 2X5 Amp 200 Volt

Data Sheet

Negotiable
STPR1020CG
STPR1020CG

Other


Data Sheet

Negotiable
STPR1020CR
STPR1020CR

Other


Data Sheet

Negotiable
STPR1020CT
STPR1020CT

STMicroelectronics

Rectifiers 2X5 Amp 200 Volt

Data Sheet

Negotiable
STPR120A
STPR120A

STMicroelectronics

Rectifiers 1.0 Amp 200 Volt

Data Sheet

Negotiable
