SN74LVTH16373DGGR

TI, 3.3-V ABT 16-BIT TRANSPARENT D-TYPE, TSSOP48, –0.5V to 4.6V, 96mA, 48mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.47~0.48 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.47~0.48

PartNumber:: SN74LVTH16373DGGR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-16

From Other Seller

Part Number:SN74LVTH16373DGGR
US $0.47 - 0.48
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN74LVTH16373DGGR device is a 16-bit transparent D-type latch with 3-state outputs. The SN74LVTH16373DGGR is designed for low-voltage (3.3-V) VCC operation, but with the capability to provide a TTL interface to a 5-V system environment. The device of the SN74LVTH16373DGGR is particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers.

Parametrics

SN74LVTH16373DGGR absolute maximum ratings: (1)Supply voltage range: –0.5V to 4.6V; (2)Input voltage range: -0.5V to 7V; (3)Voltage range applied to any output in the high-impedance or power-off state: -0.5V to 7V; (4)Voltage range applied to any output in the high state: -0.5V to VCC+0.5V; (5)Current into any output in the low state: SN54LVTH16373:96mA, SN74LVTH16373: 128mA; (6)Current into any output in the high state: SN54LVTH16373:48mA, SN74LVTH16373: 64mA; (7)Input clamp current: VI＜0: -50mA, VO＜0: -50mA; (8)Package thermal impedance: DGG package 70℃, DL package 63℃, GQL/ZQL package 36℃; (9)Storage temperature range: -65℃ to 150℃.

Features

SN74LVTH16373DGGR features: (1)Members of the Texas Instruments Widebus Family; (2)State-of-the-Art Advanced BiCMOS Technology (ABT) Design for 3.3-V Operation and Low Static-Power Dissipation; (3)Support Mixed-Mode Signal Operation (5-V Input and Output Voltages With 3.3-V VCC); (4)Support Unregulated Battery Operation Down to 2.7 V; (5)Typical VOLP (Output Ground Bounce) ＜0.8 V at VCC = 3.3 V, TA = 25℃; (6)Ioff and Power-Up 3-State Support Hot Insertion; (7)Bus Hold on Data Inputs Eliminates the Need for External Pullup/Pulldown Resistors; (8)Distributed VCC and GND Pins Minimize High-Speed Switching Noise; (9)Flow-Through Architecture Optimizes PCB Layout; (10)Latch-Up Performance Exceeds 500 mA Per JESD 17; (11)ESD Protection Exceeds JESD 22 2000-V Human-Body Model (A114-A) 200-V Machine Model (A115-A).
