SN74LVC02AD

SN74LVC02AD, QUADRUPLE 2-INPUT POSITIVE-NOR GATE, SOP14, –0.5V to 6.5 V, –50 mA, ±50 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.08~0.08 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.08~0.08

PartNumber:: SN74LVC02AD

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-13

From Other Seller

Part Number:SN74LVC02AD
US $0.08 - 0.08
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN74LVC02AD is a quadruple 2-input positive-nor gate. The SN74LVC02AD is designed for 1.65-V to 3.6-V VCC operation. The SN74LVC02AD performs the Boolean function Y = A + B or Y = A×B in positive logic.

Parametrics

SN74LVC02AD absolute maximum ratings: (1)VCC Supply voltage range: –0.5V to 6.5 V; (2)VI Input voltage range: –0.5V to 6.5 V; (3)VO Output voltage range: –0.5V to VCC + 0.5 V; (4)IIK Input clamp current VI ＜0: –50 mA; (5)IOK Output clamp current VO ＜0: –50 mA; (6)IO Continuous output current: ±50 mA; (7)Continuous current through VCC or GND: ±100 mA; (8)θJA Package thermal impedance: D package: 86℃/W, DB package: 96℃/W, NS package: 76 ℃/W, PW package: 113℃/W, RGY package: 47℃/W; (9)Tstg Storage temperature range: –65℃ to 150℃; (10)Ptot Power dissipation TA = –40℃ to 125℃: 500mW.

Features

SN74LVC02AD features: (1)Operate From 1.65 V to 3.6 V; (2)Specified From –40℃ to 85℃, –40℃ to 125℃, and –55℃ to 125℃; (3)Inputs Accept Voltages to 5.5 V; (4)Max tpd of 4.4 ns at 3.3 V; (5)Typical VOLP (Output Ground Bounce) ＜0.8 V at VCC = 3.3 V, TA = 25℃; (6)Typical VOHV (Output VOH Undershoot)＞2 V at VCC = 3.3 V, TA = 25℃; (7)Latch-Up Performance Exceeds 250 mA Per JESD 17; (8) ESD Protection Exceeds JESD 22 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), 1000-V Charged-Device Model (C101).
