Product Summary
The SN74ALS05ADR is a hex inverter with open-collector outputs. The SN74ALS05ADR contains six independent hex inverters with open-collector outputs. The SN74ALS05ADR performs the Boolean function Y = A. The open-collector outputs require pullup resistors to perform correctly. These outputs can be connected to other open-collector outputs to implement active-low wired-OR or active-high wired-AND functions. Open-collector devices are often used to generate higher VOH levels.
Parametrics
SN74ALS05ADR absolute maximum ratings: (1)Supply voltage, VCC: 7 V; (2)Input voltage, VI: 7 V; (3)Off-state output voltage: 7 V; (4)Operating free-air temperature range, TA:0℃ to 70℃; (5)Storage temperature range:–65℃ to 150℃.
Features
SN74ALS05ADR feature: Package Options Include Plastic Small-Outline (D) Packages, Ceramic Chip Carriers (FK), and Standard Plastic (N) and Ceramic (J) 300-mil DIPs.
