Product Summary
The SLC-S170E is a Chip Multilayer Coupler.
Parametrics
SLC-S170E absolute maximum ratings: (1)Coupling: 26 +/- ddB at 935-960MHz; 21 +/- 1dB at 1710-1785MHz; (2)Insertion Loss: insertion loss: 0.3dB max at 935-960MHz; 0.5dB max at 1710-1785MHz; (3)Isolation: 30dB typ; (4)Return Loss: 17dB min; (5)Handling Power: 1W max; (6)Temperature Range: -35 to 85℃.
Diagrams
 |
