Product Summary

The SI4431DY-TI is a P-Channel Logic Level PowerTrench MOSFET. It is produced using Fairchild Semiconductor’s advanced PowerTrench process that has been especially tailored to minimize on-state resistance and yet maintain superior switching performance. The SI4431DY-TI is well suited for low voltage and battery powered applications where low in-line power loss and fast switching are required. The SI4431DY-TI is used in DC/DC converter, Load switch, Motor Drive.

Parametrics

SI4431DY-TI absolute maxing ratings: (1)Drain-Source Voltage VDSS: -30 V; (2)Gate-Source Voltage VGSS: ±20 V; (3)Continuous Drain Current ID: -6.3 A; (4)Power Dissipation for Single Operation PD: 2.5 W; (7)Operating Junction and Storage Temperature Range TJ, Tstg: –55 to 150 ℃.

Features

SI4431DY-TI features: (1)-6.3 A, -30 V. RDS(ON) = 0.032 Ω@ VGS = -10 V, RDS(ON) = 0.05 Ω@ VGS = -4.5 V; (2)Low gate charge; (3)Fast switching speed; (4)High performance trench technology for extremely low RDS(ON); (5)High power and current handling capability.

Diagrams

SI4431DY-TI diagram

Si4401BDY
Si4401BDY
Other

Data Sheet
Negotiable
SI4401BDY-T1-E3
SI4401BDY-T1-E3
Vishay/Siliconix
MOSFET 40V 10.5A 0.014Ohm
Data Sheet
0-1: $1.06
1-25: $0.84
25-50: $0.79
50-100: $0.76
SI4401BDY-T1-GE3
SI4401BDY-T1-GE3
Vishay/Siliconix
MOSFET 40V 10.5A 2.9W 14mohm @ 10V
Data Sheet
0-1: $1.06
1-10: $0.84
10-50: $0.80
50-100: $0.76
SI4401DDY-T1-GE3
SI4401DDY-T1-GE3
Vishay/Siliconix
MOSFET 40V 16.1A P-CH MOSFET
Data Sheet
0-1: $0.58
1-25: $0.44
25-100: $0.39
100-250: $0.34
SI4401DY
SI4401DY
Vishay/Siliconix
MOSFET 40V 10.5A 3W
Data Sheet
Negotiable
SI4401DY-E3
SI4401DY-E3
Vishay/Siliconix
MOSFET 40V 10.5A 3W
Data Sheet
Negotiable
