Product Summary
The PS2801-4 is an optically coupled isolator containing a GaAs light emitting diode and an NPN silicon phototransistor in a plastic SOP for high density applications.
Parametrics
PS2801-4 absolute maximum ratings: (1)Forward Current (DC): 50 mA; (2)Reverse Voltage: 6 V; (3)Power Dissipation Derating: 0.6 mW/℃; (4)Power Dissipation: 60 mW/ch; (5)Peak Forward Current: 1 A; (6)Transistor Collector to Emitter Voltage: 80 V; (7)Emitter to Collector Voltage: 6 V; (8)Collector Current: 50 mA/ch; (9)Power Dissipation Derating: 1.2 mW/℃.
Features
PS2801-4 features: (1)High isolation voltage (BV = 2 500 Vr.m.s.); (2)Small and thin package (4,16-pin SOP, Pin pitch 1.27 mm); (3)High collector to emitter voltage (VCEO = 80 V); (4)High-speed switching (tr = 3 ms TYP., tf = 5 ms TYP.); (5)UL approved: File No. E72422 (S); (6)VDE0884 approved (Option): PS2801-4 only; (7)Operating number of taping product: PS2801-1-F3, F4, PS2801-4-F3, F4.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PS2801-4-A |
CEL |
Transistor Output Optocouplers Hi-Iso Photo 4-Ch |
Data Sheet |
|
|
|||||||||||||
PS2801-4-F3-A |
CEL |
Transistor Output Optocouplers Hi-Iso Photo 4-Ch |
Data Sheet |
|
|
|||||||||||||
PS2801-4-F4-A |
CEL |
Transistor Output Optocouplers Hi-Iso Photo 4-Ch |
Data Sheet |
|
|
|||||||||||||
PS2801-4-V-F4-A |
CEL |
Transistor Output Optocouplers Quad sgl Tr DC Couplr |
Data Sheet |
|
|
|||||||||||||
PS2801-4-F3 |
CEL |
Transistor Output Optocouplers Hi-Iso Photo 4-Ch |
Data Sheet |
Negotiable |
|
|||||||||||||
PS2801-4 |
NEC/CEL |
Transistor Output Optocouplers Hi-Iso Photo 4-Ch |
Data Sheet |
Negotiable |
|
