PCF8591

single-chip, single-supply, low power, 8-bit, CMOS data acquisition device, DIP, -0.5 to +8.0 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.00~5.00

PartNumber:: PCF8591

Brand:: NXP Semiconductors - nxp | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-30

From Other Seller

Part Number:PCF8591
US $0.00 - 5.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PCF8591 is a single-chip, single-supply low power 8-bit CMOS data acquisition device with four analog inputs, one analog output and a serial I2C-bus interface. Three address pins A0, A1 and A2 are used for programming the hardware address, allowing the use of up to eight devices connected to the I2C-bus without additional hardware. Address, control and data to and from the PCF8591 are transferred serially via the two-line bidirectional I2C-bus. The functions of the PCF8591 include analog input multiplexing, on-chip track and hold function, 8-bit analog-to-digital conversion and an 8-bit digital-to-analog conversion. The maximum conversion rate is given by the maximum speed of the I2C-bus.

Parametrics

PCF8591 absolute maximum ratings: (1)VDD, supply voltage (pin 16): -0.5 to +8.0 V; (2)VI, input voltage (any input): -0.5 to VDD + 0.5 V; (3)II, DC input current: ±10 mA; (4)IO, DC output current: ±20 mA; (5)IDD, ISS, VDD or VSS current: ±50 mA; (6)Ptot, total power dissipation per package: 300 mW; (7)PO, power dissipation per output: 100 mW; (8)Tamb, operating ambient temperature: -40 to +85℃; (9)Tstg, storage temperature: -65 to +150℃.

Features

PCF8591 features: (1)Single power supply; (2)Operating supply voltage 2.5 V to 6 V; (3)Low standby current; (4)Serial input/output via I2C-bus; (5)Address by 3 hardware address pins; (6)Sampling rate given by I2C-bus speed; (7)4 analog inputs programmable as single-ended or differential inputs; (8)Auto-incremented channel selection; (9)Analog voltage range from VSS to VDD; (10)On-chip track and hold circuit; (11)8-bit successive approximation A/D conversion; (12)Multiplying DAC with one analog output.
