Product Summary

The MC9S08AC16MFGE is an 8-bit microcontroller unit. It is available with a variety of modules, memory sizes, memory types, and package types.

Parametrics

MC9S08AC16MFGE absolute maximum ratings: (1)Supply voltage:–0.3V to +5.8V; (2)Input voltage:–0.3V to VDD+0.3V; (3)Instantaneous maximum current Single pin limit (applies to all port pins): ±25mA; (4)Maximum current into VDD:120mA; (5)Storage temperature:–55℃ to +150℃; (6)Maximum junction temperature:150℃.

Features

MC9S08AC16MFGE features: (1)Active background mode for code development; (2)CPU shuts down to conserve power; (3)System clocks running; (4)Full voltage regulation maintained; (5)System clocks stopped; voltage regulator in standby; (6)Stop2:Partial power down of internal circuits, RAM contents retained; (7)Stop3:All internal circuits powered for fast recovery.

Diagrams

MC9S08AC16MFGE pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MC9S08AC16MFGE
MC9S08AC16MFGE
Freescale Semiconductor
8-bit Microcontrollers (MCU) 8B 16K FLASH 4K RAM
Data Sheet
0-1: $1.56
1-25: $1.37
25-50: $1.32
50-100: $1.07
