LTC1149CS

stepdown switching regulator controller, 16-SOIC, 48V, LTC1149CS

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.27~1.27 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.27~1.27

PartNumber:: LTC1149CS

Brand:: Linear Technology - Linear | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-13

From Other Seller

Part Number:LTC1149CS
US $1.27 - 1.27
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LTC1149CS is synchronous stepdown switching regulator controller featuring automatic Burst ModeTM operation to maintain high efficiencies at low output currents. The device drives external complementary power MOSFETs at switching frequencies up to 250kHz using a constant off-time current-mode architecture. The LTC1149CS incorporates automatic power saving Burst Mode operation when load currents drop below the level required for continuous operation. The applications of the LTC1149CS include: Notebook and Palmtop Computers, Portable Instruments, Battery-Operated Digital Devices, Industrial Power Distribution, Avionics Systems, Telecom Power Supplies.

Parametrics

LTC1149CS absolute maximum ratings: (1)Input Supply Voltage (Pin 2): – 15V to 60V; (2)VCC Output Current (Pin 3): 50mA; (3)VCC Input Voltage (Pin 5): 16V; (4)Continuous Output Current (Pins 4, 13): 50mA; (5)Sense Voltages (Pins 8, 9): VIN 3 12.7V, 13V to –0.3V; VIN < 12.7V, (VCC + 0.3V) to –0.3V; (6)Shutdown Voltages (Pins 10, 15): 7V; (7)Operating Temperature Range: 0 to 70℃; (8)Temperature Range: –40 to 85℃; (9)Junction Temperature (Note 1): 125℃; (10)Storage Temperature Range: – 65 to 150℃; (11)Lead Temperature (Soldering, 10 sec): 300℃.

Features

LTC1149CS features: (1)Operation to 48V Input Voltage; (2)Ultrahigh Efficiency: Up to 95%; (3)Current Mode Operation for Excellent Line and Load Transient Response; (4)High Efficiency Maintained over Wide Current Range; (5)Logic-Controlled Micropower Shutdown; (6)Short-Circuit Protection; (7)Very Low Dropout Operation: 100% Duty Cycle; (8)Synchronous FET Switching for High Efficiency; (9)Adaptive Nonoverlap Gate Drives; (10)Available in 16-Pin Narrow SO Package.
