Product Summary

The C2328 is a Silicon NPN Epitaxial Transistor. The C2328 is designed for use in power amplifier applications and power switching applications.

Parametrics

C2328 absolute maximum ratings: (1)Collector Cutoff Current, ICBO: 0.1 uA max when VCB=30V, IE=0; (2)Emitter Cutoff Current, IEBO: 0.1 uA max when VEB=5V, IC=0; (3)Collector-Base Breakdown Voltage, BVCBO: 30 V min when IC=0.1mA; (4)Collector-Emitter Breakdown Voltage, BVCEO: 30 V min when IC=10mA; (5)Emitter-Base Breakdown Voltage, BVEBO: 5.0 V min when IE=0.1mA; (6)DC Current Gain, hFE: 80 to 400V when VCE=2V, IC=0.5A; (7)Collector Saturation Voltage, VCE(sat): 0.5 V max when IC=1A, IB=50mA.

Features

C2328 features: (1)Low collector saturation voltage; (2)Complementary to A1020.

Diagrams

C2328 Chip Appearance
