Product Summary
The BD8632FV-E2 is an NPN silicon darlington transistor with diode and resistors in a plastic package similar to TO202. The collectors of the two transistors are electrically connected to the metallic mounting area. The BD8632FV-E2 for AF applications are outstanding for a particulary high current gain. It is useful as complementary AF push-pull output stages for color TV correction stages.
Parametrics
BD8632FV-E2 absolute maximum ratings: (1)VCEO: 60V; (2)VCBO: 60V; (3)VEBO: 5V; (4)IC: 4A; (5)ICM: 7A; (6)IB: 0.1A; (7)Tstg: -55 to +150℃; (8)Tj: 150℃; (9)Ptot: 15W.
Features
BD8632FV-E2 specifications: (1)RthJA: 62.5K/W; (2)RthJC: 8.3K/W.
Diagrams
 |
