Product Summary

The BB202 is a variable capacitance diode. It is fabricated in planar technology, and encapsulated in the SOD523 ultra small SMD plastic package. The applications of the BB202 are Electronic tuning in FM radio, Voltage Controlled Oscillators (VCO).

Parametrics

BB202 absolute maximum ratings: (1)continuous reverse voltage:6V; (2)continuous forward current:10 mA; (3)storage temperature:-55℃ to +85℃; (4)operating junction temperature:-55℃ to +85℃.

Features

BB202 features: (1)Very steep C/V curve; (2)C0.2: 30.5 pF; C2.3: 9.5 pF; (3)C0.2 to C2.3 ratio: min. 2.5; (4)Very low series resistance; (5)Ultra small SMD plastic package.

Diagrams

BB202 pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BB202 /T3
BB202 /T3
NXP Semiconductors
Varactor Diodes TUNER DIODE
Data Sheet
Negotiable
BB202,135
BB202,135
NXP Semiconductors
Varactor Diodes TUNER DIODE
Data Sheet
0-7400: $0.12
7400-10000: $0.12
10000-12000: $0.11
BB202LX T/R
BB202LX T/R
NXP Semiconductors
Varactor Diodes TUNER DIODE
Data Sheet
Negotiable
BB202LX,315
BB202LX,315
NXP Semiconductors
Varactor Diodes TUNER DIODE
Data Sheet
0-1: $0.36
1-25: $0.31
25-100: $0.27
100-250: $0.23
BB202M
BB202M
Other

Data Sheet
Negotiable
BB202,115
BB202,115
NXP Semiconductors
Varactor Diodes VAR CAP 6V
Data Sheet
0-1: $0.36
1-25: $0.31
25-100: $0.27
100-250: $0.23
BB202
BB202
Other

Data Sheet
Negotiable
