Product Summary
The BAV70 is a dual surface mount switching diode.
Parametrics
BAV70 absolute maximum ratings: (1)Non-Repetitive Peak Reverse Voltage:100V; (2)Peak Repetitive Reverse Voltage:75V; (3)Working Peak Reverse Voltage:75V; (4)DC Blocking Voltage:75V; (5)RMS Reverse Voltage:53V; (6)Forward Continuous Current:300mA; (7)Average Rectified Output Current:150mA; (8)Repetitive Peak Forward Current:450mA; (9)Non-Repetitive Peak Forward Surge Current:@ t = 1.0μs:2.0A, @ t = 1.0s:1.0A; (10)Power Dissipation:350mW; (11)Thermal Resistance Junction to Ambient Air:357℃/W; (12)Operating and Storage Temperature Range:-65℃ to +150℃.
Features
BAV70 features: (1)Fast Switching Speed; (2)Surface Mount Package Ideally Suited for Automatic Insertion; (3)For General Purpose Switching Applications; (4)High Conductance; (5)Lead Free/RoHS Compliant; (6)Qualified to AEC-Q101 Standards for High Reliability.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BAV70 |
Taiwan Semiconductor |
Diodes (General Purpose, Power, Switching) 70 Volt 200mA 225mW |
Data Sheet |
|
|
||||||||||||
 |
BAV70,215 |
NXP Semiconductors |
Diodes (General Purpose, Power, Switching) SW DBL 75V 215MA HS |
Data Sheet |
|
|
||||||||||||
 |
BAV70_L99Z |
Fairchild Semiconductor |
Rectifiers 70V 200mA |
Data Sheet |
Negotiable |
|
||||||||||||
|
BAV70_Q |
Fairchild Semiconductor |
Rectifiers 70V 200mA |
Data Sheet |
Negotiable |
|
||||||||||||
|
BAV70_S00Z |
Fairchild Semiconductor |
Rectifiers High Conductance Ultra Fast |
Data Sheet |
Negotiable |
|
||||||||||||
|
BAV70215 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BAV70-7 |
Diodes Inc. |
Diodes (General Purpose, Power, Switching) 70V 350mW |
Data Sheet |
Negotiable |
|
||||||||||||
|
BAV70-7-F |
Diodes Inc. |
Diodes (General Purpose, Power, Switching) 70V 350mW |
Data Sheet |
|
|
||||||||||||
