Product Summary

The ADC0832 is an 8-bit successive approximation A/D converter with a serial I/O and configurable input multiplexer with up to 8 channels. The serial I/O of the ADC0832 is configured to comply with the NSC MICROWIRE. serial data exchange standard for easy interface to the COPS. family of processors, and can interface with standard shift registers or μPs. The 2-, 4- or 8-channel multiplexer ADC0832 is software configured for single-ended or differential inputs as well as channel assignment.

Parametrics

ADC0832 absolute maximum ratings: (1)Input Current per Pin: ±5 mA; (2)Package: ±20 mA; (3)Storage Temperature: -65℃ to +150℃; (4)Package Dissipation at TA=25℃ (Board Mount): 0.8W.

Features

ADC0832 features: (1)Operates ratiometrically or with 5 VDC voltage reference; (2)No zero or full-scale adjust required; (3)2-, 4- or 8-channel multiplexer options with address logic; (4)Shunt regulator allows operatiowith high voltage supplies; (5)0V to 5V input range with single 5V power supply; (6)Remote operatiowith serial digital data link; (7)TTL/MOS input/output compatible; (8)0.3" standard width, 8-, 14- or 20-piDIP package; (9)20 PiMolded Chip Carrier Package (ADC0838 only); (10)Surface-Mount Package.

Diagrams

ADC0832 Typical Application

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ADC0832
ADC0832

Other


Data Sheet

Negotiable
ADC0832A
ADC0832A

Other


Data Sheet

Negotiable
ADC0832B
ADC0832B

Other


Data Sheet

Negotiable
ADC0832CCN
ADC0832CCN

National Semiconductor (TI)

ADC (A/D Converters)

Data Sheet

0-400: $1.03
400-520: $0.89
520-1000: $0.79
1000-2520: $0.76
ADC0832CCN/NOPB
ADC0832CCN/NOPB

National Semiconductor (TI)

ADC (A/D Converters)

Data Sheet

0-1: $1.82
1-25: $1.47
25-100: $1.32
100-250: $0.92
ADC0832CCWM
ADC0832CCWM

National Semiconductor (TI)

ADC (A/D Converters)

Data Sheet

0-300: $1.24
300-500: $1.07
500-1000: $0.82
1000-5000: $0.79
ADC0832CCWM/NOPB
ADC0832CCWM/NOPB

National Semiconductor (TI)

ADC (A/D Converters)

Data Sheet

0-1: $1.85
1-25: $1.51
25-100: $1.36
100-250: $1.14
ADC0832CCWMX
ADC0832CCWMX

National Semiconductor (TI)

ADC (A/D Converters)

Data Sheet

0-1000: $0.82
1000-5000: $0.79
