Product Summary
The 74LVC08AD is a high-performance, low-power, low-voltage, Si-gate CMOS device, superior to most advanced CMOS compatible TTL families. Inputs can be driven from either 3.3 or 5 V devices. This feature allows the use of the 74LVC08AD as translators in a mixed 3.3 and 5 V environment. It provides the 2-input AND function.
Parametrics
74LVC08AD absolute maximum ratings: (1)VCC, supply voltage: 2.7 to 3.6 V for maximum speed performance; 1.2 to 3.6 V for low-voltage applications; (2)VI, input voltage: 0 to 5.5 V; (3)VO, output voltage: 0 V to CC V; (4)Tamb, operating ambient temperature: -40 to +125℃; (5)tr, tf, input rise and fall times: 0 to 20 ns/V when VCC = 1.2 to 2.7 V; 0 to 10 ns/V when VCC = 2.7 to 3.6 V.
Features
74LVC08AD features: (1)5 V tolerant inputs for interfacing with 5 V logic; (2)Wide supply voltage range from 1.2 to 3.6 V; (3)CMOS low power consumption; (4)Direct interface with TTL levels; (5)Inputs accept voltages up to 5.5 V; (6)Complies with JEDEC standard no. 8-1A; (7)ESD protection: HBM EIA/JESD22-A114-A exceeds 2000 V; MM EIA/JESD22-A115-A exceeds 200 V; (8)Specified from -40 to +85℃ and -40 to +125℃.
Diagrams
