Product Summary
The XC6206P212MR is a highly precise, low power consumption, high voltage, positive voltage regulator. It is manufactured using CMOS and laser trimming technologies. The XC6206P212MR provides large currents with a significantly small dropout voltage. It consists of a current limiter circuit, a driver transistor, a precision reference voltage and an error correction circuit. The XC6206P212MR is compatible with low ESR ceramic capacitors. It is selectable in 0.1V increments within a range of 1.2Vto 5.0V. SOT-23, SOT-89, TO-92 and USP-6B packages are available.
Parametrics
XC6206P212MR absolute maximum ratings: (1)Input Voltage, VIN: 7.0 V; (2)Output Current, IOUT: 500mA; (3)Output Voltage, VOUT: VSS – 0.3 ~ VIN + 0.3 V; (4)Operating Temperature Range, Topr: - 40 ~ + 85℃; (5)Storage Temperature Range, Tstg: - 55 ~ + 125℃.
Features
XC6206P212MR features: (1)Maximum Output Current: 250mA (5.0V type); (2)Dropout Voltage: 250mV @ 100mA (3.0V type); (3)Maximum Operating Voltage: 6.0V; (4)Output Voltage Range: 1.2V ~ 5.0V (0.1V increments); (5)Highly Accurate; (6)Low Power Consumption; (7)Operating Temperature Range: -40 ~ 85℃; (8)Low ESR Capacitor; (9)Current Limit Circuit Built-in; (10)Ultra Small Package.
Diagrams
 |
