Product Summary
The TPS2115PWR is an autoswitching power multiplexer. It enables seamless transition between two power supplies, such as a battery and a wall adapter, each operating at 2.8-5.5 V and delivering up to 1 A. The TPS2115PWR includes extensive protection circuitry, including user-programmable current limiting, thermal protection, inrush current control, seamless supply transition, cross-conduction blocking, and reverse-conduction blocking. These features greatly simplify designing power multiplexer applications. The TPS2115PWR is used in PCs, PDAs, Digital Cameras, Modems, Cell phones, Digital Radios, MP3 Players.
Parametrics
TPS2115PWR absolute maximum ratings: (1)VI Input voltage range IN1, IN2, D0, D1, ILIM: -0.3 V to 6 V; (2)VO Output voltage range OUT, STAT: -0.3 V to 6 V; (3)IO Output sink current STAT: 5 mA; (4)IO Continuous output current: 1.5 A; (5)TJ Operating virtual junction temperature range: -40℃ to 125℃; (6)Tstg Storage temperature range: -65℃ to 150℃; (7)Lead temperature soldering 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.
Features
TPS2115PWR features: (1)Two-Input, One-Output Power Multiplexer With Low rDS(on) Switches: 84 mΩ Typ ; (2)Reverse and Cross-Conduction Blocking; (3)Wide Operating Voltage Range: 2.8 V to 5.5 V; (4)Low Standby Current: 0.5 μA Typical; (5)Low Operating Current: 55 μA Typical; (6)Adjustable Current Limit; (7)Controlled Output Voltage Transition Times, Limits Inrush Current and Minimizes Output Voltage Hold-Up Capacitance; (8)CMOS and TTL Compatible Control Inputs; (9)Manual and Auto-Switching Operating Modes; (10)Thermal Shutdown; (11)Available in a TSSOP-8 Package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TPS2115PWR |
Texas Instruments |
Power Switch ICs - Power Distribution Dual In/Single Out Autoswitch Power MUX |
Data Sheet |
|
|
||||||||||||
|
TPS2115PWRG4 |
Texas Instruments |
Power Switch ICs - Power Distribution Dual In/Single Out Autoswitch Power MUX |
Data Sheet |
|
|
||||||||||||
