Product Summary
The SN74LVC86APWR is a quadruple 2-input exclusive-OR gate. The SN74LVC86APWR is designed for 1.65-V to 3.6-V VCC operation. The SN74LVC86APWR performs the Boolean function Y = A×B or Y = AB + AB in positive logic.
Parametrics
SN74LVC86APWR absolute maximum ratings: (1)Supply voltage range: –0.5V to 6.5 V; (2)Input voltage range: –0.5V to 6.5V; (3)Output voltage range: –0.5V to VCC + 0.5 V; (4)Input clamp current VI＜0: –50 mA; (5)Output clamp current VO＜0: –50 mA; (6)Continuous output current: ±50 mA; (7)Continuous current through VCC or GND: ±100 mA; (8)Package thermal impedance: 113℃/W; (9)Storage temperature range: –65℃ to 150℃; (10)Ptot Power dissipation TA =–40℃ to 125℃: 500mW.
Features
SN74LVC86APWR features: (1)Operate From 1.65 V to 3.6 V; (2)Specified From –40℃ to 85℃, –40℃ to 125℃, and –55℃ to 125℃; (3)Inputs Accept Voltages to 5.5 V; (4)Max tpd of 4.6 ns at 3.3 V; (5)Typical VOLP (Output Ground Bounce)＜0.8 V at VCC = 3.3 V, TA = 25℃; (6)Typical VOHV (Output VOH Undershoot)＞2 V at VCC = 3.3 V, TA = 25℃; (7)Latch-Up Performance Exceeds 250 mA Per JESD 17; (8) ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), 1000-V Charged-Device Model (C101).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74LVC86APWR |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quad 2 Input |
Data Sheet |
|
|
||||||||||||
|
SN74LVC86APWRE4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Exclusive-OR Gate |
Data Sheet |
|
|
||||||||||||
|
SN74LVC86APWRG4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Exclusive-OR Gate |
Data Sheet |
|
|
||||||||||||
