Product Summary
The SN74LV32ADBR is a quadruple 2-input positive-OR gate. The SN74LV32ADBR is designed for 2-V to 5.5-V VCC operation. The SN74LV32ADBR performs the Boolean function Y=A×B or Y=A+B in positive logic. It is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the devices when they are powered down.
Parametrics
SN74LV32ADBR absolute maximum ratings: (1)Supply voltage range, VCC: -0.5V to 7V; (2)Input voltage range, VI: -0.5V to 7V; (3)Voltage range applied to any output in the high-impedance or power-off state, VO: -0.5V to 7V; (4)Output voltage range, VO: -0.5V to VCC+0.5V; (5)Input clamp current, IIK (VI＜0): -20mA; (6)Output clamp current, IOK (VO＜0): -50mA; (7)Continuous output current, IO (VO = 0 to VCC): ±25mA; (8)Continuous current through VCC or GND: ±50mA; (9)Package thermal impedance, θJA: 96℃/W; (10)Storage temperature range, Tstg: -65℃ to 150℃.
Features
SN74LV32ADBR features: (1)2-V to 5.5-V VCC Operation; (2)Max tpd of 6.5 ns at 5V; (3)Typical VOLP (Output Ground Bounce)＜0.8V at VCC=3.3V, TA=25℃; (4)Typical VOHV (Output VOH Undershoot)＞2.3V at VCC=3.3V, TA=25℃; (5)Support Mixed-Mode Voltage Operation on All Ports; (6)Ioff Supports Partial-Power-Down Mode Operation; (7)Latch-Up Performance Exceeds 250mA Per JESD 17; (8)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), 1000-V Charged-Device Model (C101).
