The SN74LS259BDR is an 8-bit addressable latch. The SN74LS259BDR is designed for general purpose storage applications in digital systems. Specific uses of the SN74LS259BDR include working registers, serial-holding registers, and active-high decoders or demultiplexers. They are multifunctional devices capable of storing single-line data in eight addressable latches, and being a 1-of-8 decorder or demultiplexer with active-high outputs.
Parametrics
SN74LS259BDR absolute maximum ratings: (1)Supply voltage: 7V; (2)Input voltage: 5.5V; (3)Operating free-air temperature range: 0℃ to 70℃; (4)Storage temperature range: -65℃ to 150℃.
Features
SN74LS259BDR features: (1)8-bit parallel-Out Storage Register Performs; (2)Asynchronous Parallel Clear; (3)Active High Decoder; (4)Enable/Disable Input Simplified Expansion; (5)Expandable for N-bit Applications; (6)Four District Functional Modes; (7)Package Options Include Ceramic Chip Carriers and Flat Packages in Addition to Plastic and Ceramic DIPs; (8)Dependable Texas Instruments Quality and Reliability.
