Product Summary
The SN74HC241NSR is an octal buffer and line driver. It is designed specifically to improve both the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. The SN74HC241NSR is organized as two 4-bit buffers/drivers with separate output-enable (1OE and 2OE) inputs. When 1OE is low or 2OE is high, the SN74HC241NSR passes noninverted data from the A inputs to the Y outputs. When 1OE is high or 2OE is low, the outputs for the respective buffers/drivers are in the high-impedance state.
Parametrics
SN74HC241NSR absolute maximum ratings: (1)Supply voltage range:-0.5 V to 7 V; (2)Input clamp current:±20 mA; (3)Output clamp current:±20 mA; (4)Continuous output current:±35 mA; (5)Continuous current through VCC or GND:±70 mA; (6)Package thermal impedance:60℃/W; (7)Storage temperature range:-65℃ to 150℃.
Features
SN74HC241NSR features: (1)Wide Operating Voltage Range of 2 V to 6 V; (2)High-Current Outputs Drive Up To 15 LSTTL Loads; (3)Low Power Consumption, 80-μA Max ICC; (4)Typical tpd = 11 ns; (5)±6-mA Output Drive at 5 V; (6)Low Input Current of 1μA Max; (7)3-State Outputs Drive Bus Lines or Buffer Memory Address Registers.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74HC241NSR |
Texas Instruments |
Buffers & Line Drivers Octal Buff/Line Drvr W/3-State Otpt |
Data Sheet |
|
|
||||||||||||
|
SN74HC241NSRE4 |
Texas Instruments |
Buffers & Line Drivers Octal Buff/Line Drvr W/3-State Otpt |
Data Sheet |
|
|
||||||||||||
|
SN74HC241NSRG4 |
Texas Instruments |
Buffers & Line Drivers Octal Buffers And Line Drivers |
Data Sheet |
|
|
||||||||||||
