Product Summary
The SN74ALVC04DR is a hex inverter. The SN74ALVC04DR contains six independent inverters designed for 1.65-V to 3.6-V VCC operation. The SN74ALVC04DR performs the Boolean function Y = A.
Parametrics
SN74ALVC04DR absolute maximum ratings: (1)Supply voltage range: -0.5V to 4.6V; (2)Input voltage range: -0.5V to 4.6V; (3)Output voltage range: -0.5V to VCC+0.5V; (4)Input clamp current VI＜0: -50 mA; (5)Output clamp current VO＜0: -50 mA; (6)Continuous output current: ±50 mA; (7)Continuous current through VCC or GND: ±100 mA; (8)Package thermal impedance: 86℃/W; (9)Storage temperature range: -65℃ to 150℃.
Features
SN74ALVC04DR features: (1)Operates From 1.65 V to 3.6 V; (2)Max tpd of 2.8 ns at 3.3 V; (3)±24-mA Output Drive at 3.3 V; (4)Latch-Up Performance Exceeds 250 mA Per JESD 17; (5)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), 1000-V Charged-Device Model (C101).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74ALVC04DR |
Texas Instruments |
Inverters HEX INVERTER |
Data Sheet |
|
|
||||||||||||
|
SN74ALVC04DRE4 |
Texas Instruments |
Inverters HEX INVERTER |
Data Sheet |
|
|
||||||||||||
|
SN74ALVC04DRG4 |
Texas Instruments |
Inverters Hex Inverter |
Data Sheet |
|
|
||||||||||||
