Product Summary
The SN74ABT126NS is a bus buffer gate. It features independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable (OE) input is low. When VCC is between 0 and 2.1 V, the SN74ABT126NS is in the high-impedance state during power up or power down. However, to ensure the high-impedance state above 2.1 V, OE should be tied to GND through a pulldown resistor; the minimum value of the resistor is determined by the current-sourcing capability of the driver.
Parametrics
SN74ABT126NS absolute maximum ratings: (1)Supply voltage range, VCC: –0.5 V to 7 V; (2)Input voltage range, VI: –0.5 V to 7 V; (3)Voltage range applied to any output in the high or power-off state, VO: –0.5 V to 5.5 V; (4)Current into any output in the low state, IO: 128 mA; (5)Input clamp current, IIK (VI < 0): –18 mA; (6)Output clamp current, IOK (VO < 0): –50 mA; (7)Package thermal impedance, θJA: 96℃/W; (8)Storage temperature range, Tstg: –65 to 150℃.
Features
SN74ABT126NS features: (1)Typical VOLP (Output Ground Bounce) <1 V at VCC = 5 V, TA = 25℃; (2)High-Impedance State During Power Up and Power Down; (3)High-Drive Outputs (–32-mA IOH, 64-mA IOL); (4)Ioff and Power-Up 3-State Support Hot Insertion; (5)Latch-Up Performance Exceeds 500 mA Per JESD 17; (6)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A); 200-V Machine Model (A115-A).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74ABT126NSR |
Texas Instruments |
Buffers & Line Drivers Quad Bus Buff Gate With 3-State Outputs |
Data Sheet |
|
|
||||||||||||
|
SN74ABT126NSRG4 |
Texas Instruments |
Buffers & Line Drivers Quad Bus Buffer |
Data Sheet |
|
|
||||||||||||
|
SN74ABT126NSRE4 |
Texas Instruments |
Buffers & Line Drivers Quad Bus Buff Gate With 3-State Outputs |
Data Sheet |
|
|
||||||||||||
