Product Summary

The SN65HVD05D is a high output RS-485 transceiver. It combines a 3-state differential line driver and differential line receiver. The SN65HVD05D is designed for balanced data transmission and interoperate with ANSITIA/EIA-485-A and ISO 8482E standard-compliantdevices. The driver is designed to provide a differential output voltage greater than that required by thesestandards for increased noise margin. The applications of the SN65HVD05D include: Data Transmission Over Long or Lossy Lines or Electrically Noisy Environments, Profibus Line Interface, Industrial Process Control Networks, Point-of-Sale (POS) Networks, Electric Utility Metering, Building Automation, Digital Motor Control.

Parametrics

SN65HVD05D absolute maximum ratings: (1)Supply voltage range, Vcc: –0.3V to 6V; (2)Voltage range at A or B: –9V to 14V; (3)Input voltage range at D, DE, R or RE: –0.5V to VCC+0.5V ; (4)Voltage input range, transient pulse, A and B, through 100: –50V to 50V; (5)Storage temperature range, Tstg: –65℃ to 150℃; (6)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

SN65HVD05D features: (1)Minimum Differential Output Voltage of 2.5 VInto a 54-Ω Load ; (2)Open-Circuit, Short-Circuit, and Idle-BusFailsafe Receiver; (3)1/8thUnit-Load Option Available (Up to 256Nodes on the Bus) ; (4)Bus-Pin ESD Protection Exceeds 16 kV HBM ; (5)Driver Output Slew Rate Control Options ; (6)Electrically Compatible With ANSITIA/EIA-485-A Standard ; (7)Low-Current Standby Mode: 1 μA Typical ; (8)Glitch-Free Power-Up and Power-DownProtection for Hot-Plugging Applications ; (9)Pin Compatible With Industry Standard SN75176.

Diagrams

SN65HVD05D diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN65HVD05DRG4
SN65HVD05DRG4
Texas Instruments
Bus Transceivers High-Output RS-485 Transceiver
Data Sheet
0-1850: $1.13
1850-2000: $1.09
2000-2500: $1.09
2500-5000: $1.04
SN65HVD05DR
SN65HVD05DR
Texas Instruments
Buffers & Line Drivers High-Output RS-485 Transceiver
Data Sheet
0-1850: $1.13
1850-2000: $1.09
2000-2500: $1.09
2500-5000: $1.04
SN65HVD05DG4
SN65HVD05DG4
Texas Instruments
Bus Transceivers RS485 Hi Out
Data Sheet
0-1: $2.38
1-25: $2.11
25-100: $1.88
100-250: $1.48
SN65HVD05D
SN65HVD05D
Texas Instruments
Buffers & Line Drivers RS485 Hi Out
Data Sheet
0-1: $2.42
1-25: $2.21
25-100: $1.88
100-250: $1.70
