Product Summary
The SI9410DY-T1 is an N-channel enhancement mode field-effect transistor. The SI9410DY-T1 is in a plastic package using TrenchMOS technology. The applications of the SI9410DY-T1 include DC to DC convertors, DC motor control, Lithium-ion battery applications, Notebook PC, Portable equipment applications.
Parametrics
SI9410DY-T1 absolute maximum ratings: (1)Drain-Source Voltage: 30V; (2)Gate-Source Voltage: ±20V; (3)Continuous Drain Current: TA=25℃, 7.0A; TA=70℃, 5.8A; (4)Pulsed Drain Current: 20A; (5)Continuous Source Current: 2.8A; (6)Power Dissipation: TA=25℃, 2.5W; TA=70℃, 1.6W; (7)Operating Junction and Storage Temperature Range: -55℃ to 150℃; (8)Maximum Junction-to-Ambient: 50℃/W.
Features
SI9410DY-T1 features: (1) Low on-state resistance; (2) Fast switching; (3) Trench MOS technology.
Diagrams
 |
